Detail Parameters
| Junction Box | IP68, three diodes |
| Output Cable | 4mm², +400, -200mm/±1400mm |
| Glass | Single glass, 3.2mm coated tempered glass |
| Weight | 25.3kg |
Electrical Characteristics
| Module type | LR5-54HPH-495W | LR5-54HPH-500W | LR5-54HPH-505W | LR5-54HPH-510W | LR5-54HPH-515W |
| Testing Condition | STC | STC | STC | STC | STC |
| Pmax/W | 495 | 500 | 505 | 510 | 515 |
| Voc/V | 45.40 | 45.55 | 45.70 | 45.85 | 46.00 |
| Isc/A | 13.82 | 13.90 | 13.97 | 14.05 | 14.13 |
| Vmp/V | 38.23 | 38.38 | 38.53 | 38.68 | 38.83 |
| Imp/A | 12.95 | 13.03 | 13.11 | 13.19 | 13.27 |
*STC: lrradiance 1000 W/m²,Cell Temperature 25℃,Air Mass AM1.5
